LOCKWOOD PRIMARY ELECTRIC MORTICE LOCK NCYL SC

Code:

3570ELM0SC

Price:

$971.07 inc GST

Price:

$882.79 exl GST

RRP:

$1,330.93 inc GST

You save 34%

Brand

Brisbane

In Stock

Lockwood 3570ELM0SC Electric Mortice Lock – No Cylinder

Finish: Satin Chrome
Backset: 60mm as standard, 89mm & 127mm available
Voltage: 12VDC - 24VDC Operating Voltage
Monitoring: Yes – Refer Below
Field Changeable: Fail Safe / Fail Secure configuration
Keyed Alike: Available
Compatible with Restricted Master Keying: Yes
Door Thickness: 32-50mm
SCEC Rated: Yes – Rated to SL2 & SL3
Fire Rated: Yes
AS1428.1 Disabled Compliant: Yes
Warranty: 1 Year Electronic Manufacturer Warranty & 25 Years Mechanical Manufacturer Warranty

Additional Information

Monitoring - Dead latched & Locked / Door position - Reed switch / Key Override Monitoring on both sides of door / Request to exit-REX / LED Indication
Cabling - 1.6 metre Length of Cable with 12 pin socket supplied with each Lock. Recommended cable: 18AWG (0.82mm²) cable runs up to 30m
Compatible with Lockwood Series Door Furniture – Including 1820/70 Led Furniture

Application:

SCEC Rated

Type:

Australian Mortice Lock

Fixing:

Morticed

Function:

Electronic

Finish:

Satin Chrome
